| Type |
Type CCM-100 |
Type CCM-150 |
| Output |
100W |
150W |
| Voltage |
100V(single phase) |
200V(single phase) |
200V(three phase) |
380V(three phase)50hz |
| Rated current |
2.2/2.3A |
0.7/0.64A |
0.9/0.85A |
0.5A(50Hz) |
| Number of revolutions |
370/450rpm |
| Maximum mixing capacity |
1,000L |
2,000L |
| Ambient temperature for use |
40℃ |
| Maximum operating temperature |
80℃ |
| Maximum liquid viscosity |
300cP |
| Maximum liquid specific gravity |
1.3 |
| Method of speed reduction |
Timing belt |
| Protection class |
IP54 or equivalent |
| Installation |
JIS10K65A Flange |
| Shaft |
φ16×900L made of SUS316-grade stainless steel
|
| Impeller |
φ175/φ145(50Hz/60Hz) made of PPC 3-vane propeller
|
φ195/φ165(50Hz/60Hz) made of PPC 3-vane propeller
|
| Optional items |
Change in shaft length (maximum: 1,200L), change in shaft material, change in impeller diameter, change in impeller material (PPS, PVDF), pipe exterior
|
| Main body weight |
About 10kg |
*The maximum mixing capacity shows performance with clear water. The mixing capacity decreases if the solution to be mixed has a viscosity or specific gravity that is higher than that of clear water.
*The standard material of the liquid contact parts are: SUS316-grade stainless steel for shaft, and PPC for the impeller.
*Mixing of a solvent, etc. cannot be performed.
*The mixer cannot be used in an explosion-proof area.
